1984-1994 Chevrolet / GMC S10 Blazer/S10 Pickup/S15 Jimmy/S15 Pickup Leaf Springs | 22-859

Year: 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996
Make: Chevrolet
Model: S10 Blazer, S10 Pickup, S15 Jimmy, S15 Pickup
Part Number: 22-859
OEM Number: 15642471
Width: 2.5 in.
PL-1SE (A): 26 in.
PL-1LE (BE): 28 in.
Eye Type/Bushing S.E.: Ber/RB-117
Eye Type/Bushing L.E.: Ber/RB-117
Arch (C): 6 in.
Grading: 2/360 2ND 1/490
Number of Leaves: 2/1
Pack Thickness (D): 1.3125 in.
Capacity: 1100 lbs.
Remarks: Two stage. Sold individually.

Experience unmatched durability and performance with the 22-859 leaf springs, meticulously crafted from 100% American steel. Engineered to provide optimal support and suspension for heavy-duty Chevrolet trucks from 1984-1994, these essential components guarantee a precise fit every time.

Our leaf springs are manufactured with unwavering precision, ensuring they meet the highest quality standards in the industry. Designed to withstand even the harshest road conditions, you can trust their reliability and longevity thanks to our rigorous quality control checks.

Have questions about which leaf spring is right for your vehicle or how it will enhance its performance? Our team of knowledgeable professionals is always ready to assist you. Reach out via phone at 1-800-922-3283 or email us at store.superiorspring@gmail.com - we're here whenever you need guidance or expert advice.

We take great pride in offering top-tier products that consistently exceed industry benchmarks. When choosing our high-quality North America-made leaf springs, rest assured that your heavy-duty Chevrolet vehicles from '84-'94 will operate at peak efficiency no matter what challenging conditions lie ahead.

When replacing leaf springs, the removed u-bolts cannot be reused.

Suspension u-bolts are manufactured with a smooth rolled thread, while the mating hi-nuts are manufactured with sharp cut threads. When a u-bolt is tightened to its recommended torque level, the u-bolt threads stretch as they mate with the hi-nuts. Although it is not always visible to the naked eye, this damages the threads. Removed the hi-nuts from the u-bolt will cause a cross-threading that will not allow the u-bolt to be adequately re-torqued.Chevy
