1983-1994 Chevrolet / GMC G10/G20/G30/G1500/G2500/G3500/S10 Jimmy/S10 Pickup/Oldsmobile Bravada Leaf Springs | 22-687

Year: 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994
Make: Chevrolet
Model: Bravada, G10, G20, G30, G1500, G2500, G3500, S10 Blazer, S10 Pickup, S15 Jimmy, S15 Pickup
Part Number: 22-687
OEM Number: 14060056
Width: 2.5 in.
PL-1SE (A): 26 in.
PL-1LE (BE): 28 in.
Eye Type/Bushing S.E.: Ber/RB-117
Eye Type/Bushing L.E.: Ber/RB-117
Arch (C): 7.5 in.
Grading: 3/307 2ND 1/525
Number of Leaves: 3/1
Pack Thickness (D): 1.5 in.
Capacity: 1450 lbs.
Remarks: Two stage. Sold individually.

Introducing the 22-687: The Ultimate Leaf Springs for Chevrolet Oldsmobile Bravada Trucks

Unleash the power of your heavy-duty vehicles with our superior leaf springs, expertly crafted from premium-grade American steel. Built to deliver unrivaled durability and performance, these essential components are meticulously designed to provide optimal support and suspension.

No road condition is too tough for our leaf springs. Manufactured with unwavering precision and engineered to meet stringent quality standards, they can withstand even the harshest environments with ease. Rest assured that every spring has undergone rigorous quality control checks to ensure their reliability and longevity.

Got questions about compatibility? Our dedicated team of experts is always available at your service! Whether you need assistance in finding the perfect fit for your vehicle or have specific inquiries about its outstanding performance capabilities, we're here to help. Reach out directly through a phone call at 1-800-922-3283 or send us an email at store.superiorspring@gmail.com.

We take immense pride in offering top-tier products that consistently exceed industry benchmarks all proudly manufactured right here in North America! With our high-quality leaf springs powering your Chevrolet Oldsmobile Bravada trucks, you can trust that they'll operate flawlessly even under the most demanding conditions.

Don't settle for anything less than excellence when it comes to upgrading your vehicle's suspension system - choose Superior Spring today!

When replacing leaf springs, the removed u-bolts cannot be reused.

Suspension u-bolts are manufactured with a smooth rolled thread, while the mating hi-nuts are manufactured with sharp cut threads. When a u-bolt is tightened to its recommended torque level, the u-bolt threads stretch as they mate with the hi-nuts. Although it is not always visible to the naked eye, this damages the threads. Removed the hi-nuts from the u-bolt will cause a cross-threading that will not allow the u-bolt to be adequately re-torqued.Chevy
