1983-1991 Chevrolet / GMC P40/P60 Leaf Springs | 22-729

Year: 1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991
Make: Chevrolet
Model: P40, P60
Part Number: 22-729
OEM Number: 2094061
Width: 3 in.
PL-1SE (A): 29.625 in.
PL-1LE (BE): 29.625 in.
Arch (C): 7.75 in.
Grading: 8/401 2ND 3/499 PD/360 RR 2/447
Number of Leaves: 8/3/PD/2
Pack Thickness (D): 5.9375 in.
Capacity: 10500 lbs.
Remarks: Two stage. Rad. Rod Arch (E): Flat. Rad. S.E. (F) x Rod L.E. (G): 3 1/2 x 25 1/2. Sold individually.

Experience unmatched durability and performance with our 22-729 leaf springs. Crafted from 100% American steel, these essential components provide optimal support and suspension for a precise fit with heavy-duty Chevrolet P40 trucks from 1983-1991.

Our leaf springs are manufactured to the highest quality standards, ensuring unwavering precision and reliability that can withstand even the harshest road conditions. Rigorous quality control checks guarantee their longevity so you can have peace of mind knowing your vehicle is equipped with top-tier equipment.

Have questions about compatibility or need guidance on finding the right fit? Our team of experts is always here to assist you. Reach out via phone at 1-800-922-3283 or email us at store.superiorspring@gmail.com we're ready to lend our knowledge to help optimize your ride.

Proudly manufactured in the North America, our high-quality leaf springs consistently surpass industry benchmarks. Trust them to keep your heavy-duty Chevrolet P40 vehicles operating at peak performance no matter how demanding the circumstances get.

When replacing leaf springs, the removed u-bolts cannot be reused.

Suspension u-bolts are manufactured with a smooth rolled thread, while the mating hi-nuts are manufactured with sharp cut threads. When a u-bolt is tightened to its recommended torque level, the u-bolt threads stretch as they mate with the hi-nuts. Although it is not always visible to the naked eye, this damages the threads. Removed the hi-nuts from the u-bolt will cause a cross-threading that will not allow the u-bolt to be adequately re-torqued.Chevy
