2004-2021 Nissan Titan Rear Pre-Bent U-Bolt Kit | 361-783K
Secure online checkout
Year: 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021
Make: Nissan
Model: Titan
Includes 2 u-bolts with nuts and washers.
| Diameter (A) | Dist. Between Legs (B) | Leg Length (C) | Bend | Grade |
| 9/16" | 2 3/8" | 6 5/8" | Square | 5 |
- A: Measure the diameter of the rod at the thread.
- B: Measure the length of the leg, from the top of the inside of the bend.
- C: Measure the width between the inside of the legs.
- Bend: Note the type of bend: Round, Semi-Round, Square, or Forged Top.
U-Bolt Torque Guide
U-Bolts that bave ben torqued to a set preload are recommended to be re-torqued after a short time to take up the stretch in the material.
U-Bolts that have been well lubricated with an anti-sieze compound will have a torque range between plated and unplated values.
All of the below values are general guidelines. The OEM Service Manual on specific models always takes precedence over the values shown.
| Size | Material Grade | Max. Torque Ft.-Lbs. Plated | Max. Torque Ft.-Lbs. Unplated |
| 3/8 - 24 | 5 | 21 | 36 |
| 7/16 - 20 | 5 | 33 | 44 |
| 1/2 - 20 1/2 - 20 |
5 8 |
52 64 |
70 87 |
| 9/16 - 18 9/16 - 18 |
5 8 |
75 93 |
100 124 |
| 5/8 -18 5/8 -18 |
5 8 |
107 143 |
132 177 |
| 3/4 - 16 3/4 - 16 |
5 8 |
190 253 |
234 313 |
| 7/8 - 14 7/8 - 14 |
5 8 |
304 405 |
375 500 |
| 1 - 14 | 8 | 758 | 1010 |
| 1 1/8 - 12 | 8 | 848 | 1131 |
| 1 1/4 - 12 | 8 | 1163 | 1151 |
U-Bolts must be tightened and torqued using a cross pattern sequence.
Tighten #1 then #4 to partial toque, then partial torque #2 and #3.
Using the same sequence, fully torque U-Bolt Nots.
DO NOT RE-USE U-BOLTS.
| Model | Titan |
|---|---|
| Number of Leaves | 11 |
