1994-2002 Dodge Ram 1500/Ram 2500 4WD Leaf Springs | 34-1343
Secure online checkout
2,860 lbs. carrying capacity.
There is a heavy-duty version of this spring available: 34-1343HD.
This item is OUT OF STOCK. However, there is another spring which fits the same application: the 34-1341. Year 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002
Make: Dodge
Model: Ram 2500, Ram 3500
OEM Number: 52039228
Width 3 in.
PL-1 S.E. (A) 27 7/8 in.
PL-1 L.E. (B) 32 1/8 in.
Eye Type/Bushing S.E. Ber/RB-224*
Eye Type/Bushing L.E. Rev/RB-224/1*
Arch (C) 5 11/16 in.
Number of Leaves 3/1
Grading 2/401 1/423 2ND 1/788
Pack Thickness (D) 2 1/16 in.
Spring Capacity at Pad 2,860 lbs.
Remarks Two stage; 3500
* We substitute alternate bushings that cannot be used to replace the indicated OE.
Sold individually.
Unleash the unmatched power and durability of 34-1343 leaf springs – crafted from premium American steel for unbeatable performance. These indispensable components are tailor-made to deliver exceptional support and suspension, providing a flawless fit for heavy-duty Dodge trucks manufactured between 1994-2002.
Precision-engineered with unwavering attention to detail, our leaf springs meet the highest quality standards in the industry. Designed to conquer even the toughest road conditions, they offer unrivaled reliability and longevity thanks to our rigorous quality control checks.
Need expert advice on finding the perfect match for your vehicle? Our team of knowledgeable professionals is always here to assist you every step along the way. Whether it's guidance on compatibility or questions about their outstanding performance, we're just one call away at 1-800-922-3283 or an email away at store.superiorspring@gmail.com.
At our company, we don't settle for less than excellence when it comes to delivering top-tier leaf springs that outshine competitors in terms of both functionality and craftsmanship. With prideful manufacturing conducted right here in America, choosing our high-quality leaf springs guarantees optimal operation for your heavy-duty Dodge vehicles from '94-'02 – regardless if you face demanding terrains or challenging working conditions.
Important note: When replacing leaf springs, the removed u-bolts cannot be reused.
Suspension u-bolts are manufactured with a smooth rolled thread, while the mating hi-nuts are manufactured with sharp cut threads. When a u-bolt is tightened to its recommended torque level, the u-bolt threads stretch as they mate with the hi-nuts. Although it is not always visible to the naked eye, this damages the threads. Removing the hi-nuts from the u-bolt will cause cross-threading that will not allow the u-bolt to be adequately re-torqued.
| Model | Ram 1500 |
|---|---|
| Vehicle Option | - |
| OEM Number | 52039228 |
| Number of Leaves | 5/1 |
