1992-2006 Ford E150 Leaf Springs | 43-1033HD
1,685 lbs. carrying capacity.
There is an OEM replacement version of this spring available: 43-1033.
Year: 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
Make: Ford
Model: E150
OEM Number: F2UZ5560A / F2UA5560CA
Width 2 1/2 in.
PL-1 S.E. (A) 23 7/8 in.
PL-1 L.E. (B) 31 in.
Eye Type/Bushing S.E. Ber/RB-207
Eye Type/Bushing L.E. Ber/RB-160
Arch (C) 6 1/8 in.
Number of Leaves 4/1
Grading 4/360 2ND 1/770
Pack Thickness (D) 2 13/16 in.
Leaf Capacity at Pad 2,250 lbs.
Remarks Two stage; Replaces Dallas similar design in pairs
Sold individually.
Upgrade Your Ford E150 with Superior 43-1033HD Leaf Springs!
Introducing the 43-1033HD Leaf Springs: Unmatched Durability and Performance for Your Heavy-Duty Ford E150 Trucks
When it comes to providing optimal support and suspension, accept no substitutes. Our 100% American steel leaf springs are meticulously crafted to deliver unparalleled durability and performance for heavy-duty Ford E150 trucks manufactured between 1992 and 2006.
Precision-engineered with unwavering attention to detail, our leaf springs are built to endure even the harshest road conditions. From rigorous quality control checks during manufacturing to meeting the highest industry standards, we guarantee reliability that lasts.
Have questions about application or compatibility? Need expert guidance on finding the perfect fit? Look no further than our dedicated team of knowledgeable professionals. With years of experience in leaf spring technology under their belts, they're here for you every step of the way.
Call us at 1-800-922-3283 or drop us an email at store.superiorspring@gmail.com - because your satisfaction is paramount.
As leaders in producing top-tier leaf springs that surpass all industry benchmarks time after time, trust your heavy-duty Ford E150 vehicles' peak operation even in demanding conditions with our high-quality products - proudly manufactured right here in America.
When replacing leaf springs, the removed u-bolts cannot be reused.
Suspension u-bolts are manufactured with a smooth rolled thread, while the mating hi-nuts are manufactured with sharp cut threads. When a u-bolt is tightened to its recommended torque level, the u-bolt threads stretch as they mate with the hi-nuts. Although it is not always visible to the naked eye, this damages the threads. Removed the hi-nuts from the u-bolt will cause a cross-threading that will not allow the u-bolt to be adequately re-torqued.
| Model | E150 |
|---|---|
| Vehicle Option | - |
| Capacity lbs | 1685 |
| Number of Leaves | 4/1 |
